Smart Personnel Management · Solution 6

On/Off-Duty Intelligent Management System
Smart Badge + Bluetooth Beacon + Indoor LoRa Gateway

In factories and office buildings, whether an employee is on duty or how long they have been away has long been a blind spot in management. This solution equips each employee with a smart badge, deploys Bluetooth beacons in every room, and aggregates data through indoor LoRa gateways—delivering real-time visibility of on-duty status, automatic tallying of off-duty duration, and room-level indoor geo-fencing. This on and off duty personnel tracking system and RTLS turns badge, beacon and gateway data into clear attendance records.

Room-levelPositioning accuracy, upgradable to meter-level
Automatic tallyingFull record of on-duty/off-duty duration
Indoor fencingInstant alerts for boundary breach / prolonged stay
Low powerBadge long battery life, beacons maintenance-free*
On/Off-Duty Management
01 · Management Pain Points

On-duty status you can't see, off-duty duration you can't account for

Traditional manual roll calls and checks are costly, coarse-grained, and prone to disputes

🤷

Guessing whether someone is on duty

A team leader only learns who is on duty after a walk-through; when office staff step out for meetings or personal errands, managers have no visibility at all.

⏱️

Off-duty duration is a muddle

Off duty for ten minutes or two hours? Without objective data, performance reviews lack a basis, and tracing a person's whereabouts after a safety incident is difficult.

🏢

Indoor GPS fails completely

In workshops and office buildings GPS fails completely—you have no idea which floor or room someone is on.

02 · Technical Principle

One beacon per room; the badge "listens" to locate

Bluetooth beacons broadcast continuously; the badge scans to sense—which room a person is in becomes clear at a glance

Plant / office floor plan illustration Workshop A Beacon ① 👤 Badge A Workshop B Beacon ② Corridor Office Beacon ③ 👤 Badge B Key area (high precision) Tri-lateration 📡 Indoor LoRa Gateway 1–2 units per floor Badge scans beacon → reports to gateway via LoRa
Working method: One Bluetooth beacon is placed in each room, continuously broadcasting its location identity. The badge keeps scanning nearby beacons and sends “I am near Beacon ①” (i.e., “I am in Workshop A”) together with its badge ID via LoRa to the indoor gateway, which then uploads to the platform via 4G/Ethernet. For areas requiring high precision (e.g., hazardous work zones, valuable-asset rooms), multiple beacons are deployed in one room and RSSI tri-lateration achieves meter-level positioning, with fine-grained indoor fencing.
03 · Deployment Options

Room-level or meter-level — choose by management granularity

No need to go finest overnight—launch room-level first, then densify key areas

📍 Room-level Positioning

For: workshops, offices, meeting rooms, warehouses, and other routine on-duty management
Workshop A Beacon × 1 Workshop B Beacon × 1 One beacon per room · know “which room a person is in”
  • Deploy 1 Bluetooth beacon per room for minimal installation work
  • The badge scans the strongest beacon to determine the room it is in
  • Full visibility of on-duty/off-duty status, which room, and entry/exit times
  • Battery-powered beacons last years, virtually maintenance-free
High precision

🎯 Meter-level tri-lateration + indoor fencing

For: hazardous work zones, cleanrooms, valuable-asset rooms, key workstations
Key area 👤 RSSI tri-lateration Meter-level accuracy
  • Deploy 3+ beacons in a single room for tri-lateration
  • Accuracy up to 1–3 m, supporting workstation-level management
  • Indoor electronic fencing: entry/exit/prolonged-stay timeout triggers alerts instantly
  • Can be mixed with room-level deployment, focusing investment on key areas
💡 Recommendation: deploy conventional areas by “one beacon per room”, and densify hazardous/key areas with tri-lateration—spend the budget where it matters most.
04 · System Architecture

Four-layer data link, from workstation to management dashboard

Badge scans beacon to locate → reports via LoRa → gateway → cloud

🪪 Smart badge × N Scan beacon · LoRa uplink 📡 Bluetooth Beacon 1 per room · ×3 for precision 📶 Indoor LoRa Gateway 1–2 per floor · full coverage ☁️ Management Cloud On-duty stats · fencing 🖥️📱 Dashboard / phone BLE broadcast LoRa uplink 4G / Ethernet Web/API
Link description: Inside the room the badge continuously scans Bluetooth beacons, resolves its location identity, and reaches the indoor gateway in a single LoRa hop (strong wall penetration; 1–2 gateways per floor cover the whole building); the gateway aggregates and uploads to the cloud via 4G/Ethernet. Throughout, the badge only needs to “scan + send a short message”, consuming very little power—one charge lasts weeks.
05 · Core Hardware

Three-piece set, ready to use with minimal installation

Smart Badge
Personnel Terminal

Smart Badge

Scan Bluetooth beacons to locate · report via LoRa
  • BLE scans beacons to determine the room/workstation
  • LoRa reports directly to the indoor gateway
  • Low-power design, weeks of battery life
  • Card-style wearable, zero burden for employees
Bluetooth Beacon
Location Reference

Bluetooth Beacon GB30

Ceiling/wall-mounted · continuously broadcasts location identity
  • One beacon per room, the room-level positioning reference
  • Tri-point deployment in key areas for meter-level accuracy
  • Battery-powered, lifespan up to several years
  • Wire-free, peel-and-stick or screw mounting
Indoor LoRa Gateway
Aggregation & Uplink

Indoor LoRa Gateway

Dual antennas · floor-level coverage · 4G/Ethernet uplink
  • Multi-channel concurrent reception
  • 1–2 units per floor cover the entire floor
  • PoE / DC powered, plug and play
  • Uploads to the cloud platform via 4G/Ethernet
🖥️
Software Platform

On-Duty Management Cloud Platform

Dashboard + Web + Mobile
  • On-duty map; live status refresh for all personnel
  • Automatic off-duty duration tallying, one-click report export
  • Indoor electronic fencing; prolonged-stay / boundary-breach alerts
  • Open API to integrate with attendance / HR / OA systems
06 · Platform Features

From roll-call to data-driven management

🗺️

On-duty map

Floor plan shows in real time which room each person is in, with colors distinguishing on-duty/off-duty/away.

⏱️

Off-duty duration statistics

Automatically records each person's entry/exit time per room; off-duty start/end and cumulative duration are tallied automatically.

🚨

Off-duty timeout alert

When key-post personnel leave beyond a set duration, the system instantly notifies the team leader/responsible person.

📊

Attendance & man-hour reports

Auto-summarized by person/team/day/month, giving an evidence basis for attendance assessment.

🚧

Indoor electronic fencing

Virtual boundaries for hazardous and valuable-asset zones; entry/prolonged stay/unauthorized leaving trigger instant alerts.

🧭

Trajectory replay & traceability

Replay any person's trajectory over any period; safety incidents and accountability are traceable.

07 · Alert System

Tiered alerts that bring order to management response

Alarm TypeTrigger ConditionLevelPush Target
Key-post off-duty timeoutPerson leaves a key post beyond the set durationEmergencyTeam leader, safety officer, supervising leader
Fence intrusionUnauthorized personnel entering hazardous/valuable-asset zonesEmergencyArea responsible person, safety officer
Prolonged-stay timeoutPerson stays in an area longer than expected (e.g., lingering in a hazardous zone)ImportantArea responsible person
Badge offlineBadge hasn't reported for a long time (possibly dead / removed / out of coverage)ImportantAdministrator
Low-battery reminderBadge / beacon battery below thresholdNoticeAdministrator
Attendance anomalyAttendance-rule anomalies such as late arrival, early leave, missing check-inNoticeHR, department head
08 · Solution Advantages

Why choose this solution

🎯

Truly usable indoor positioning

Bluetooth beacon + LoRa combination, starting at room-level and optional meter-level, fully eliminating GPS indoor failure.

🔋

Ultra-low power, maintenance-free

Beacon batteries last years; badges run for weeks—the whole system needs almost zero daily maintenance.

🛠️

Minimal installation work

Beacons are wire-free and stick-on ready; 1–2 gateways per floor—a building is deployed and effective the same day.

🧾

Data-driven management

On/off duty, room entry/exit, and trajectory are fully recorded; assessment and traceability leave no room for disputes.

🔗

Open and easy to integrate

API integrates with attendance, HR, OA, and security systems without changing existing management workflows.

💰

Controllable cost

Choose room-level or meter-level as needed, scale elastically with headcount, with clear ROI.

09 · Application Scenarios

Factories and buildings: one deployment, multiple scenarios benefit

🏭

Factory workshop

Worker on-duty supervision, hazardous-zone fencing, team attendance statistics

🏢

Office building

Staff on-duty status, outing management, department man-hour analysis

📦

Warehousing & logistics

In-warehouse personnel distribution, zone permissions, prolonged-stay alerts

🧪

Lab / server room

Duty confirmation, authorized entry, operation logging
